USB / USB 2 / Rugged / Mini-B Couplers

USB 2 Mini-B Female
Waterproof Rugged Coupler

Mini-B Female to Mini-B Female
Part Number:
RR-214300-30
(xx = inches)
USB 2 Mini-B Female <br> Waterproof Rugged Coupler
Click to view part page
Click to view large image

USB 2 Mini-B Female <br> Waterproof Rugged CouplerUSB 2 Mini-B Female <br> Waterproof Rugged Coupler

3D Model - Conn. 1Panel CutoutTechnical DrawingRequest a Quote


USB 2 Mini-B Female
Waterproof Rugged Coupler


Easy Installation
The coupler design that we use on this connector makes installation so simple, and it eliminates the possibility of mis-wiring.  Just plug it and and go.

USB Waterproof Mini-B Connector
Building a new product?  Trying to find a solution that's waterproof?  This cable is right for you.  It has a female mating connector on to solder tips, which makes it perfect for a solid, production installation into your device.  Our waterproof connectors are sealed and ready to be installed into your case, controller, brief, tote, detonator, or anything else you might be installing it on.

Lightweight USB Connector
From the picture, you can see that we use a zinc alloy housing.  It's tough, but also waterproof to IP68 standards.  It's great for use in outdoor environments.  Trust our time-tested design.



Mini-B Female to Mini-B Female


Part Numbers

Available Part Numbers

  • PART# RR-214300-30
    SIZE: Coupler

Equivalent Part Numbers

  • GT214300-30 (Connector)

Additional information

What's included

  • Waterproof Rugged Mini-B Female Connector
  • Mini-B Female Connector
  • Gasket
  • Hex Nut

Specifications

  • Operating Temp: -40°C to +105°C
  • Thread: 5/8"-27 UNS
  • Waterproof Rating: IP68
  • Max Panel Thickness: 8.0 mm
  • Torque: 20kgf-cm (17in/lb)
  • Size C2

Compliance

  • RoHS Compliant
  • REACH Compliant
  • Certificate of Conformity

Buy this item

Recommended
  • Mini-B Seal Cap for zinc alloy connectors

    Seal Cap (Optional)

    Part #: RR-1C523122M
    $7.50
Price: $18.95
