USB / USB 2 / Cables / A to C / Angled C / Straight A

USB 2 Right/Left C to A
(56K Resistor) Ultra Thin

Straight A Male to Right/Left C Male
Part Number:
RR-ASCH-XXGCX
(xx = inches)
USB 2 Right/Left C to A <br> (56K Resistor) Ultra Thin
Click to view part page

Request Technical DrawingRequest a Quote


USB 2 Right/Left C to A
(56K Resistor) Ultra Thin

Perfect for Tight Robotics Builds
Our USB 2.0 A to C cables with ultra-thin cable construction are engineered for high-density robotics environments. With a minimal bend radius and reduced bulk, they’re ideal for routing through tight pathways, cable chains, or articulated arms. Despite the slim profile, they maintain full USB 2.0 performance and shielding integrity. Available in custom lengths, orientations, and overmolding options to fit your build perfectly.

Customization
Customize to your exact specifications with minimal added cost. With low order minimums, your tailored solution is always within reach.


Part Numbers

Available Part Numbers

  • PART# RR-ASCH-10GCX, SIZE: 10in (254mm)
  • PART# RR-ASCH-20GCX, SIZE: 20in (508mm)
  • PART# RR-ASCH-40GCX, SIZE: 40in (1016mm)

Additional information

What's included

  • Straight A Male Connector
  • Right/Left C Male Connector

Specifications

  • Operating Temp: -30°C to +80°C
  • Bend Radius: 12mm
  • Double Shielded
  • 30AWG Power/Ground
  • 30AWG Data pair
  • PVC Jacket
  • 3.0mm OD

Compliance

  • RoHS Compliant
  • REACH Compliant
  • Certificate of Conformity

Buy this item

Price: $16.75

Price: $18.25

Price: $20.25
